Text wrap creates a boundary around an object that allows text to flow around it. Use it for images, shapes, or text frames. Select a wrap shape in the Text Wrap panel: Wrap around bounding box, Wrap around object shape, Jump object. Specify offset values to control the distance between text and the wrap boundary. Select a contour option from the Type menu: Bounding Box, Detect Edges, Alpha Channel, Photoshop Path. Text wrap settings control the distance between wrapped text and the wrap object, as well as how text behaves on specific sides or in multi-column layouts.
InDesign itself does not offer a native warp tool for text like Illustrator or Photoshop. In this tutorial, we will explore practical approaches to achieve warped or distorted text effects when working with InDesign, including using Illustrator as a companion tool and handling text wrap to maintain layout integrity.
Using the Text Wrap feature to control how text flows
The Pen tool can be used to add or delete anchor points and the Direct Selection tool to drag anchor points and adjust the curve in related workflows when preparing type for warp-like effects in conjunction with Illustrator assets. Once you manually edit the wrap boundary, User-Modified Path appears in the Type menu. Exclude text wrap for specific frames by default, text flows around objects with text wrap applied, but you can set individual text frames to ignore text wrap. In the Composition preferences, select Text Wrap Only Affects Text Beneath. Select OK.
Why warp in InDesign is limited and how to work around it
Adobe InDesign is an amazing platform for print and editorial design, but incorporating elements and features from Illustrator can elevate your layout to an entire visually appealing level. When working with typography effects, there are limitations in Adobe InDesign. For instance, you aren't able to warp text - or add any other distortion feature to type much like you would in Illustrator or even Photoshop.
In this workflow, you can create a warp effect in Illustrator, then transfer the result into InDesign as a usable asset. It's important to note that when adding distorted text from Illustrator to InDesign, the most efficient way is to save it as an image. Keeping a master file in Illustrator for editable text - in case you ever want to go back to make changes - is a good idea.
Warping text in Illustrator as a preparatory step
Create a document in Illustrator similar in size to your InDesign layout to gauge appearance before transfer. Select the Type Tool and click on your Artboard, then type the text you would like to warp. Format the typeface, size and colour in the Properties panel. In this example, Gotham Black, 100 pt and black were used. Click the frame once with the Selection Tool and go to Effect > Warp > Wave. There are four main settings to focus on: the wave type, the Bend, and the Horizontal and Vertical distortion sliders. When satisfied, click OK.
There are a couple of ways to save this text for InDesign: you can drag and drop into your CC Library (holding Command to preserve the warp formatting), or export as a PNG with a transparent background. If you plan to tweak the warp later, save the master in Illustrator as editable text; otherwise, exporting as a PNG provides a ready-to-use raster asset for InDesign.
Alternative approaches within InDesign
If you want to mimic warping within InDesign without Illustrator, you can create the warped appearance by placing a warped graphic or vector outline inside InDesign and using the text on a path technique from Illustrator exports. InDesign does not have a direct warp option for text, but you can create a custom path and attach text to that path in Illustrator or export as PDF with transparent background to maintain editability for future updates. Once the tool is active, you can start creating a path and place text along it by clicking on the path to add text to the path. After adding text to the path, you can edit it as needed, though the path’s stroke may be visible below the text.
To remove stroke color, activate the Direct Selection Tool, select the path, and adjust stroke settings. You can also add a shape on the canvas and use the same process to type text onto the shape. For more dramatic distortion, you can create outlines to convert the text to editable paths in Illustrator, then import the result into InDesign as a placed object or PDF, preserving warp-like shapes even though the text remains non-editable in InDesign.
Practical steps to integrate warped text into an InDesign layout
- Decide whether you want a warped text look achieved via an Illustrator path or a rasterized warped text image.
- If using Illustrator: create, warp, then export as PNG with transparent background or as a PDF with preserved text where needed.
- Place the warped asset in InDesign and adjust wrapping as needed using the Text Wrap panel to control distance and behavior around the object.
- For editable text in InDesign, prefer standard typography and use layout tricks (contrast, kerning, baseline shift) rather than attempting distortion on a live text layer.
Additional tips on text wrap and layout coherence
Use the Type menu to choose a wrap contour option such as Bounding Box or Detect Edges depending on the asset. Adjust offset values to fine-tune spacing between wrapped text and the wrap boundary. If you need to ensure text never sits beside a particular object, employ the Jump object option to avoid awkward line breaks. Be mindful of multi-column layouts, as wrap behavior can vary across columns and text frames.
